A-B1PLGF46000
1/4"-28 SAE Straight Grease Fitting, 10 pcs
by Sunbelt · Fitting
Shop Supply > Grease FittingsSunbelt - Tools/Assortments > Tools
- Ships direct from the factory.
$3.31
each
Sold and shipped by GetPartFound LLC · 30-day returns on unused parts
Free standard shipping on orders over $500. Ships from the supplier's warehouse within 4 business days of your order; delivery typically takes 4 to 12 business days.
Authorized A&I Products reseller
Features and specs
| Hex Size | 5/16" |
|---|---|
| Overall Length | 13.7mm |
| Quantity | 10 |
| Shank Length | 4.6mm |
| Thread Length | 2.5mm min |
| Weight | 0.09 lb |
- This is a 1/4 inches-28 taper thread (SAE-LT), straight 0.54 inch grease fitting. It is used on most auto vehicles and on industrial equipment. SAE-LT threads conforms to society of automotive engineers lubrication thread specification. The ball check prevents dust and dirt contamination. These fittings have a ball check in the head to prevent dirt and grit from getting into the fitting, heavier wall thickness for extra strength, are zinc plated with a yellow passivated finish for maximum protection against corrosion, and have a stress relieved and tempered carbon steel spring. Every fitting is individually inspected and batch tested to 5,000 PSI and are designed to meet the demanding requirements of most automotive, agricultural, industrial, marine, truck, federal and construction equipment needs.
- 1/4"-28 SAE-LT Grease Fitting, Straight, 5/16-inch Hex, 10-pack
- Manufactured to the most stringent quality standards - TS16949 approved manufacturing.
- Fitting profile & dimensions are accurately controlled & conform to SAE, DIN, BS, JIS & IS standards.
- Heat treated to SAE J534 specification with hardness on greasing end to a minimum of 83 on Rockwell 15N scale with a case depth of 0.005" (0.13 mm) to 0.009" (0.23 mm).
- Steel fittings are plated in yellow zinc with a plating thickness of 0.0002" (5 microns) confirming to SAE J534 specification.
- Guaranteed salt spray life of over 75 hours to reduce rust.
